Orthopaediacology

Arthroscope GJ-3

J0230E
G4503

*Adopted high quality stainless steel
*Endoscope can stand of temperature of 134°C/273° F for sterilizaion
*Endoscopes adopt the Germán optic fiber
*With direction index
*Sapphire lens cover,ever abrasion
*New optic system,clear field of view

Endoscope

J0200E 0º Arthoscope
             4mm x 175mm

J0230E  30º Arthoscope
              4mm x 175mm

J0270E  70º Arthoscope
              4mm x 175mm

1  Connecting to OLYMPUS light cable                           Connecting to STORZ light cable
2 Connecting to WOLF light cable
3 Connecting to ACMI light cable

Sheath

G4500  0º Sheath two-stopcock
             5.5mm x 138mm

G4503 30º Sheath two-stopcock
            5.5mm x 138mm

G4507 70º Sheath two-stopcock
            5.5mmx 138mm

G4520  Prism puncture needle
             4.3mm x 173mm

G4540  Blunt obturator
             4.3mm x 187mm

Trocar Cannula (trocar)

G4502 Trocar cannula
            5.5mm x 74mm

G4542 Trocar
            5mm x 92.5mm

Punch forceps, Meniscus grasping forceps, Synovium forceps

G5004  Punch forceps
             5mm x 150mm

G5001 Meniscus grasping forceps
            4.8mm x 165mm

G5002 Synovium forceps, straight
            4mm x 150mm

Instrument

G5003  Needle location biopsy forceps
             4mm x 150mm

G5304  Straight scissors
            4mm x 150mm

G5302 Straight scissors(left)
            4mm x 150mm

G5303 Straight scissors(Left)
            4mm x 150mm

G5013 Forceps (0º)

G5014 Forceps ( left 45º)

G5016  Forceps( rught 45º)

Right angle probe

G5901  Right angle probe (3mm/5mm)
             5- 1.5mm x 105mm

Knife, Curette

G5401  Hook knife
             4mm x 1.2mm x 105mm

G5403  Rerosective knife
             4mm x 1mm x 105mm

G5408  Meniscus knife

G5409  Rosette knife

G5410  Half-round knife

G5404  Spade knife, straight
             4mm x 1.8mm x 105mm

G5411  Curette

Light cable

U8724   Light cable
              2m

1 Connecting to WOLF fountain
2 Connecting to STORZ fountain

Accessories of arthroscope (Endoscope)

J0200G  0 º Arthroscope (angle of field:90 º)
               4mm x 175mm
J0200CG 0 º Arthroscope (angle of field:110 º)
               4mm x 175mm

J1200 0 º Arthroscope
           3mm x 175mm

J2200 0 º Arthroscope
           2.7mm x 175mm

J0212 12 º Arthroscope
            4mm x 175mm

J0230  30 º Arthroscope (angle of field:90 º)
            4mm x 175mm
J0230CG  30 º Arthroscope (angle of field:110 º)
            4mm x 175mm

J1230  30 º Arthroscope
            3mm x 175mm

J2230 30 º Arthroscope
            2.7mm x 175mm

J0230GS 30 º Arthroscope (Stryker connector)
            4mm x 140mm

J0245G 45 º Arthroscope (angle of field:90 º)
            4mm x 175mm
J0245E 45 º Arthroscope
            4mm x 175mm

J0270G 70 º Arthroscope (angle of field:90 º)
            4mm x 175mm
J0270CG 30 º Arthroscope (angle of field:110 º)
            4mm x 175mm

J1270  70 º Arthroscope
            3mm x 175mm

J2270 70 º Arthroscope
            2.7mm x 175mm

J0290E 90 º Arthroscope
            4mm x 175mm

J02110C 110 º Arthroscope
            4mm x 175mm

Arthoscope accessories ( Sheath, Prism puncture needle)

G2703  30 º Sheath two-stopcock
             4mm x 138mm

G2720 Prism puncture needle
            3mm x 175mm

G2740 Blunt obturator
            3mm x 175mm

Discectomy system YZ-1

JZ0530

*Adopted high quality stainless steel
*Endoscope can stand of temperature of
  134 ºC/273°F for sterilization
*With direction index
*Sapphire lens cover never abrasion
*New optic system,clear field of view

Endoscope, Camera lens adaptor

JZ0530  30 º Endoscope
               4mm

U8220  Camera lens adaptor

Connecting ring, Locating penfiled

U8552  Connecting ring
             16mm
U8553  Connecting ring
             18mm
U8550  Connecting ring
             20mm

Y5905  Locating oenfiled
             2Fr
Y5906  Locating oenfiled
             4Fr

Dilator, Operating tube, Orientation rod

Y5615  Dilator
             15Fr
Y5617  Dilator
             17Fr
Y5619  Dilator
             19Fr

Y4716  Operating tube
             16Fr
Y4718  Operating tube
             18Fr
Y4720  Operating tube
             20Fr

Y5616  Orientation rod

Suction tube

Y4408A  Suction tube
                8Fr
Y4410A  Suction tube
                10Fr
Y4401A  Suction tube


Nerve hook, Probe, Dissection device

Y5904  Nerve hook

Y5902  90 º Global probe

Y5903  90 º Ball probe, short

Y5901  90 º Dissection device

Gun forceps

Y5004  40 º Gun forceps
             5mm

Y5005  90 º Gun forceps
             3mm

Marrow center forceps, Oblique scissors

Y5009A  Eagle neak marrow
                center forceps

Y5002  Marrow center forceps

Y5006  Upper curved
              marrow center forceps

Y5007  Upper curved
             marrow center forceps

Y5008  Pituitary with tooth

Y5301  Oblique scissors

Curved curette

Y5908  Curved curette
              5.2mm
Y5909  Curved curette
             3.6mm

Y5907  Straight curette
             5.2mm

Y5910  Rolling back curette
             5.2mm

Y5911  Curette, ellipse
             5.2mm

Universal holder

U8551A  Universal holder

U8551B  Snake style holder

Four edge knife, Scrape bone device, Magnetic rod, Nerve draught device

Y5401  Four edges knife

Y5913  Scrape bone device

Y5914  Magnetic rod

Y5912  Nerve draught device

BXQ Computer powerful chipping device ( with curved head of knife)

U9611Z  Control source
                Rotation rate
                1000-4000r/min

U9622Z Hand controls
              power of motor 8W

U8801  Foot switch

B5726Z  Oblique inner cutters (curved)
                4mm

B5722Z  Flat full-tooth cutters(straight)
               4mm

B5724Z  Oblique cutters(straight)
                4mm

B5747Z  Round-shapes drill(straight)
               4mm

BXQ  Computer powerful chipping device(with straight head of knife)

U9611ZS  Control source
                  Rotation rate
                  3500-9500r/min

U9622ZS  Hand controls

U8801  Foot swith

B5721ZS  Oblique inner cutters (straight)
                  4mm

B5722ZS  Flat full-tooth cutters(straight)
                 4mm

B5726ZS  Oblique cutters (straight)
                  4mm

B5747ZS  Round-shape drill (straight)
                 4mm
