Gynecology

Hysteroscope XG-5/XG-5A

J0122
J0122A

*Adopt high quality stainless steel
*Endoscope adopted German optic glass and fiber
 *With direction index
 *Sapphire lens cover never abrasion
*The unique 22°curved tube can make doctor find the left and right Fallopian tube easily
*Thinner diameter of tube can let doctor insert easily and decrease the pain ot patient *Hysteroscope with metal handle can be chosen

Endoscope

J0122        22º Curved hysteroscope
                  6.4 mm x 170 mm

J0122A        22º Curved hysteroscope
                    5.2 mm x 170 mm

1  Connecting to OLYMPUS light cable                           Connecting to STORZ light cable
2 Connecting to WOLF light cable
3 Connecting to ACMI light cable

Instrument

Instrument with normal handle

Instrument with metal handle

X5161A     Flexible biopsy forceps
                  6Fr x 430 mm

X5161B     Flexible biopsy forceps
                  (Metal handle)
                  6Fr x 430mm

X5261A     Flexible scissors
                   6Fr x 430 mm

X5261B    Flexible scissors
                   (Metal handle)
                   6Fr x 430 mm

X5163A     Flexible grasping ring forceps
                   6Fr x 430 mm

X5163B     Flexible grasping ring forceps
                  (Metal handle)
                  6Fr x 430 mm

Steel Wire, Flexible brush, Sealed cap, Light cable

X5803    Steel wire
               1 (3Fr) x 300 mm

U8661   Flexible brush

T7303   Sealed cap

U8724 Light cable
            2m
1 Connecting to WOLF fountain
2 Connecting to STORZ fountain

Accessories

J0122R      Curved hysteroscope (Handle)
                  6.4 mm x 170 mm

J0122AR      Curved hysteroscope (Handle)
                     5.2 mm x 170 mm

T7511    Infusion unit

X5162    Flexible grasping forceps
               6Frx430mm

X5164A   Flexible saw tooth forceps
                 6Fr x 430mm

X5164B  Flexible saw tooth forceps
               (Metal handle)
               6Fr x 430mm

X5165A   Flexible foreign body forceps
                 6Fr x 430mm

X5165B   Flexible foreign body forceps
               (Metal handle)
               6Fr x 430mm

Gynecology

Hysteroscope ZG-1

J0100A
J0100F

*Adopt high quality stainless steel
* Endoscope adopted German optic glass and fiber
* With direction index
* Sapphire lens cover never abrasion *Hysteroscope with metal handle can be chosen

J0100A     0º Endoscope
                 6.2mm x 205mm

J0100F      0° Endoscope
                 5.2mm x 205mm

J0112       12º Endoscope (for choice)
                 5.2mm x 206mm

J0130       30º Endoscope(for choice)
                6mm x 206mm

1  Connecting to OLYMPUS light cable                           Connecting to STORZ light cable
2 Connecting to WOLF light cable
3 Connecting to ACMI light cable

Instrument

Instrument with normal handle

Instrument with metal handle

X5161A     Flexible biopsy forceps
                  6Fr x 430 mm

X5161B     Flexible biopsy forceps
                  (Metal handle)
                  6Fr x 430mm

X5261A     Flexible scissors
                   6Fr x 430 mm

X5261B    Flexible scissors
                   (Metal handle)
                   6Fr x 430 mm

X5163A     Flexible grasping ring forceps
                   6Fr x 430 mm

X5163B     Flexible grasping ring forceps
                  (Metal handle)
                  6Fr x 430 mm

Steel Wire, Flexible brush, Sealed cap, Light cable

X5803    Steel wire
               1 (3Fr) x 300 mm

U8661   Flexible brush

T7303   Sealed cap

U8724 Light cable
            2m
1 Connecting to WOLF fountain
2 Connecting to STORZ fountain

Accessories

J0100AR     Straight tube hysteroscope
                    (Handle)
                    6.2mm x 205mm

J0100FR   Straight tube hysteroscope
                 (Handle)
                 5.2mm x 205mm

T7511 Infusion unit

X5162     Flexible grasping forceps
                6Fr x 430mm

X5164A   Flexible saw tooth forceps
                 6Fr x 430mm

 X5164B   Flexible saw tooth forceps
                 (Metal handle)
                 6Fr x 430mm

X5165A   Flexible foreign body forceps
                 6Fr x 430mm

X5165B   Flexible foreign body forceps
                 (Metal handle)
                 6Fr x 430mm

Gynecology

Hysteroscope ZG-2

J1312E
X4013
X4015

*Adopt high quality stainless steel material
*Endoscope adopted German optic fiber and galss
*With direction index
*Sapphire lens cover never abrasion
*Continuous channel can make continue flow and make more clear of field of view
*Inner sheath can be used separately
*Doctor can conveniently control the direction through straight endoscope and make operation easier
*Less outer diameter can insert easily and decrease the pain of patient
*The autoclavable endoscopes can be chosen

Endoscope

J1330E     30º Endoscope
                 3mm x 302mm

1  Connecting to OLYMPUS light cable                           Connecting to STORZ light cable
2 Connecting to WOLF light cable
3 Connecting to ACMI light cable

Outer sheath, innerSheat  & obturator, Valve

X4015   Outer sheath
              15Fr  x 209mm

X4012A  Inner sheath & obturator
               12Fr x 232mm

T7201 In-flow valve

T7211    Out-flow valve

Light cable

U8724 Light cable
            2m
1 Connecting to WOLF fountain
2 Connecting to STORZ fountain

Accessories (12º Endoscope)

J1312E     12º Endoscope
                  3mm x 302mm

X4015   Outer sheath
              15Fr  x 209mm

X4013     Inner sheath & obturator
                12Fr x 232mm

T7201C    In-flow valve

T7211    Out-flow valve

Hysteroscope ZG-3(19.5Fr)

J0330E
X4019

*Adopt high quality stainless steel material
*Endoscope adopted German optic fiber and glass
*With direction index
*Sapphire lens cover never abrasion
*No need to dilate uterus, decrease the operation time, doctor can operate conveniently in a short time
*Doctor can conveniently control the direction through straight endoscopes and make operation easier

J0330E    30º Endoscope
                4mm x 302mm

1  Connecting to OLYMPUS light cable                           Connecting to STORZ light cable
2 Connecting to WOLF light cable
3 Connecting to ACMI light cable

Working element, Obturator

X4019    Working element
               19.5Fr x 190mm

X4012    Obturator
               12Fr

Light cable

U8724 Light cable
            2m
1 Connecting to WOLF fountain
2 Connecting to STORZ fountain

Instrument

X5001       Rigid biopsy forceps
                  6Fr x 285 mm

X5301        Rigid scissors
                   6Fr x 285 mm

Accessories

T7201C    In-flow valve

T7211   Out-flow valve

T7303      Sealed cap

Hysteroscope ZG-3A/ZD-3B

ZG-3A
J1330E
X4016

ZG-3B
J1330E
X4014

*Adopt high quality stainless steel material
*Endoscope adopt German optic fiber and glass
*With direction index,Sapphire lens cover never abrasion
*Continuous channel can make continue flow and make more clear of field of view
*Less outer diameter of operator,easy to insert and can decrease the pain of patient
*No need to dilate uterus,decrease the operation time,doctor can conveniently in a short time
*Doctor can conveniently control the direction through straight endoscope and make operation easier
*The autoclavable endoscope can be chosen

Hysteroscope ZG-3A (16Fr)

J1330E      30°Endoscope
                  3mm x 302mm

Working element

X4016       Working element
                  16Fr x 198mm

Instrument

X5001      Rigid biopsy forceps
                 6Fr x 285mm

X5301       Rigid scissors
                  6Fr x 285mm

Valve, Camera lens adoptor, Steel wire, Sealed cap, light cable

T7201   In-flow valve

T7211   Out-flow valve

X5803   Steel wire
              1(3Fr) x 330mm

T7303  Sealed  cap

U8724 Light cable
            2m
1 Connecting to WOLF fountain
2 Connecting to STORZ fountain

Accessories

J1300E     0° Endoscope
                3mm x 302 mm

Hysteroscope ZG-3B (14Fr)

J1330E      30°Endoscope
                  3mm x 302mm

1  Connecting to OLYMPUS light cable                           Connecting to STORZ light cable
2 Connecting to WOLF light cable
3 Connecting to ACMI light cable

Working element

X4014   Working element
               14Fr x 191.5mm

Valve, Steel wire, Sealed cap, Light cable

T7201C   In-flow valve

T7211   Out-flow valve

X5803   Steel wire
              1(3Fr) x 330mm

T7303  Sealed  cap

U8724 Light cable
            2m
1 Connecting to WOLF fountain
2 Connecting to STORZ fountain

Resectoscope QD-2 (Rotating locked)

J0312A
Q6020A
Q4025A
Q4027A
Q6303

*Adopt high quality stainless steel material
*Endoscope adopt German optic fiber and glass fiber
*Withdirection index
*Sapphire lens cover never abrasion
*The high temperature metal ceramic head can stand more than 10000V pressure
*When outer sheath main fixed the endoscope and handle can rotate freely
*Rotating style make more convenient

Endoscope

J0312A    12º  Endoscope
                 4mm x 302mm

1  Connecting to OLYMPUS light cable                           Connecting to STORZ light cable
2 Connecting to WOLF light cable
3 Connecting to ACMI light cable

Working element

Q6010A   Working element(Active)

 Q6020A   Working element(Passive)

Electode

Q6211       Cutting loops
                  4mm x 282 mm

Q6221       Cutting loops
                  4mm x 284 mm

X6201       Cutting loops,straight
                  4mm x 283mm

Q6303      Coagulation electrode
                 4mm x 287mm

Sheath&obturator, Valve

Q4027A   Outer sheath
                 27Fr x 180mm

Q4025A   Inner sheath & obturator
                 25Fr x 195mm

T7202A   In-flow valve

HF cord, Cleaning rod, Light cable

U8412B   HF cord
                 3m

U8601C   Cleaning rod
                 3mm x 340mm

U8724 Light cable
            2m
1 Connecting to WOLF fountain
2 Connecting to STORZ fountain

ResectoscopeQD-2( Snack-in and out)

J0321D
Q6020B
Q4025B
Q4027B
Q6303

*Aadopted high quality stainless steel material
*Endoscope adopted German optic glass and fiber *With direction index
*Sapphire lens cover never abrasion
*The high temperature metal ceramic head can stand more than 10000V pressure
*Free maintenance valve
*When outer sheath main fixed the endoscope and handle can rotate freely
*Rotating style make more convenient

Endoscope

J0312D   12º  Endoscope
               4mm x 314mm

1  Connecting to OLYMPUS light cable                           Connecting to STORZ light cable
2 Connecting to WOLF light cable
3 Connecting to ACMI light cable

Working element

Q6010B   Working element(Active)
Q6020B   Working element(Passive)

Electrode

Q6211   Cutting loops
              4mm x 282mm

Q6221   Cutting loops
              4mm x 284mm

X6201   Cutting loops, straight
              4mm x 283mm

Q6303   Coagulation electrode
              4mm x 287mm

Sheath & obturator, Valve

Q4027B  Outer sheath
                27Fr x 182mm

Q4025B  Inner sheath & obturator
                25Fr x 195mm

T7202A   In-flow valve

HF cord, Cleaning rod, Light cable

U8412B   HF cord
                 3m

U8601C  Cleaning rod
                3mm x 340mm

U8724 Light cable
            2m
1 Connecting to WOLF fountain
2 Connecting to STORZ fountain
